G9S Pro All-In-One Smith Machine, Power Rack & Functional Trainer
New ArrivalWeight StackPatented Design
G9S PRO ALL-IN-ONE SMITH MACHINE & FUNCTIONAL TRAINER Weight stack all-in-one rig with a patented interchangeable pulley ratio system
The G9S Pro combines three complete training systems in one rack: a guided Smith machine, a free weight power rack and a dual stack functional trainer. The result is a highly versatile all-in-one station for home gyms, PT studios and light commercial facilities, packed into exact rack dimensions of 2030mm wide x 1735mm deep x 2130mm tall.
Two 90kg steel weight stacks power the cable towers, and the interchangeable pulley ratio lets you switch between a 1:1 ratio for heavier lifts such as lat pulldown and seated row, and a 2:1 ratio for lighter movements such as tricep pushdowns and cable flys, all from the same stack. The frame is built from heavy gauge 2.5mm steel and is rated for light commercial use.
Read on for the full specification, inclusions, optional attachments and who the G9S Pro suits before you buy.
136KGMax User Weight
555LBCable Pulley Loading Capacity
180KGTotal Weight Stack (2 x 90kg)
2030MMRack Width
What Is Included
Smith Machine & Power Rack FrameHeavy gauge 2.5mm steel frame with guided Smith station, free weight rack positions and reinforced components.
Dual 90kg Steel Weight Stacks2 x 90kg stacks, 180kg total. Individual stack plates are 6kg with clearly visible weight markings.
Metal Weight Stack ShieldsProtective metal shielding improves safety around the stacks and gives the machine a cleaner commercial appearance.
Patented 1:1 / 2:1 Tri-Pulley SystemSwitch between 1:1 for heavier movements and 2:1 for lighter isolation exercises using the same weight stack.
Multi-Angle Pull-Up HandlesMultiple grip angles with non-slip end grips plus a D-ring for assisted pull-ups using resistance bands.
Adjustable Safety Spotter ArmsExtra-long spotter arms with protective pads and inserts for softer bar contact and scratch protection.
Adjustable J-HooksSet the bar position to suit different users and exercises, with protective inserts to reduce barbell scratching.
Adjustable Dip Handles / Dip AttachmentNon-slip comfort grips with wide and narrow positions to suit different body types and training preferences.
Flip-Down Seated Row FootplateIntegrated metal footplate with non-slip surface for stable seated rows, folds away when not in use and can also be used for calf stretching.
6 Weight Plate Storage ProngsBuilt-in rear storage for both Olympic and standard plates, helping keep the training area organised.
Resistance Band Hooks / Power Band PegsAdd band resistance to Smith machine lifts without needing additional weight plates.
Integrated Storage SystemSwivel accessory hooks, 2 barbell holders, cable attachment rack and rooftop barbell rack keep accessories stored on the machine.
Double-Headed Straight BarIncluded cable attachment for pulldowns, rows and arm work.
Double-Headed Curl BarIncluded angled cable bar for curls, extensions and upper body accessory training.
Short Straight BarCompact cable attachment for curls, pressdowns and close grip movements.
Link ChainIncluded for attachment connection and flexible cable setup.
Triceps RopeFor pressdowns, face pulls, overhead extensions and rope curls.
Ankle StrapFor glute kickbacks, hip abduction and other lower body cable exercises.
Close-Grip TriangleFor seated rows, close grip pulldowns and back training.
Accessory storage: the included cable accessories can be stored at designated positions on the rear of the unit, keeping the training area tidy and easy to reset between users.
Key Features
Three Training Systems in OneCombines the controlled guided movement of a Smith machine, free weight training inside a power rack and the exercise variety of a dual stack functional trainer in one unit.
Heavy Duty Light Commercial ConstructionBuilt from premium 2.5mm heavy gauge steel with reinforced components and scratch resistant powder coating for demanding home, PT studio, school, hotel and corporate gym use.
Smooth, Secure Smith MachinePremium linear bearings and hard chrome guide rails provide smooth, quiet guided movement, while laser cut bar catches and safety systems support controlled solo lifting.
Patented 1:1 and 2:1 Tri-Pulley SystemAlternate between a 1:1 ratio for large muscle exercises such as lat pulldowns and seated rows, and a 2:1 ratio for smaller muscle exercises such as lateral raises, cable flyes and triceps pressdowns.
Aluminium Alloy PulleysCommercial-style aluminium alloy pulleys provide a smooth cable run, reduced flex and a more refined training feel than basic plastic pulley systems.
180 Degree Swivel Triple Pulley AdjustmentThe triple pulley assembly swivels through 180 degrees and uses a zinc plated adjustment handle so the cable height can be repositioned quickly for different exercises and users.
Dual 90kg Steel Weight StacksTwo 90kg stacks provide 180kg total installed stack weight. Each plate is 6kg, allowing quick pin loaded resistance changes without loading plates onto the cable system.
Metal Weight Stack ShieldsMetal stack guards improve safety around moving weight plates while giving the rear of the machine a cleaner, more finished commercial look.
65mm Spring BufferA heavy duty 65mm spring buffer helps absorb accidental impact if the Smith bar or load is dropped onto the lower stop.
Olympic and Standard Plate CompatibilityThe Smith bar can accept both Olympic and standard weight plates. Stainless steel Olympic sleeves and spring collars are included for secure plate loading.
Resistance Band IntegrationBuilt-in band hooks and pegs work with the Smith machine so resistance bands can be combined with the loaded bar for progressive resistance without buying additional plates.
Laser-Cut Smith Bar CatchPrecision laser cut catch positions allow the Smith bar to latch securely onto the stopper system during setup, reracking and safety stops.
Multi-Angle Pull-Up HandlesMultiple grip angles with non-slip end grips support close, medium, wide, pronated, supinated and neutral grip pull-up variations.
Flip-Down Row FootplateThe integrated metal footplate has a non-slip surface for stable seated rowing, flips away when not required and can also be used as a calf stretch platform.
Adjustable J-Hooks and Spotter ArmsReposition the lifting height to suit the exercise and user. Protective ABS and nylon contact surfaces help protect barbells and provide a softer landing point.
Adjustable Dip HandlesNon-slip grips and wide and narrow handle positions allow the dip station to suit different users, body sizes and movement preferences.
Integrated Weight and Accessory StorageSix plate prongs, swivel accessory hooks, two barbell holders, a cable attachment rack and rooftop barbell storage keep plates, bars and cable handles organised on the unit.
Space Efficient All-In-One DesignRack dimensions of 2030mm W x 1735mm D x 2130mm H combine three major training stations without requiring separate floor areas for a Smith machine, power rack and functional trainer.
Build quality and safety. The G9S Pro uses a premium 2.5mm steel frame, hard chrome Smith rails, linear bearings, aluminium alloy pulleys and protective metal stack shields. The patented triple pulley layout lets the same 90kg stack deliver either 90kg at a 1:1 ratio or 45kg at a 2:1 ratio. Safety and durability features include laser cut Smith catches, a 65mm spring buffer, adjustable J-hooks and spotter arms with protective contact pads, non-slip pull-up and dip grips, and an integrated non-slip row footplate. Static load testing includes 620kg on the Smith machine structure, 670kg on the J-cups and safety spotters, 340kg on the dip handles and 340kg on the chin-up handles. The cable pulley system is listed at 555lb loading capacity. The Smith bar itself is rated to 500kg and weighs 15kg.
Maximum Loading Capacity
| Smith Machine Static Loading Test | 620kg |
| Smith Bar Rated Weight Capacity | 500kg |
| Cable Pulley System | 555lb, approximately 252kg, loading capacity |
| J-Cups & Safety Spotter Arms Static Loading Test | 670kg |
| Dip Handles Static Loading Test | 340kg |
| Chin-Up Handles Static Loading Test | 340kg |
| Weight Storage Pin | 135lb, approximately 61kg |
Load rating note: static test figures describe structural test loads under controlled conditions and are not the same as a recommended day to day working load. The Smith bar's stated rated weight capacity remains 500kg.
Optional Upgrades
+ Leg Press attachment
+ Monolift attachment
+ Landmine attachment
+ Rack Knee Holder attachment
+ Jammer Arm attachment
Technical Specifications
| Machine Type | All-in-one Smith machine, power rack and dual-stack functional trainer |
| Rack Dimensions (W x D x H) | 2030mm x 1735mm x 2130mm |
| Frame Construction | Premium heavy gauge 2.5mm steel with scratch resistant powder coating |
| Commercial Rating | Rated for light commercial use including PT studios, corporate gyms, hotel gyms and schools, plus serious home gyms |
| Total Weight Stack | 180kg total, 2 x 90kg steel stacks, individual stack plates are 6kg |
| Weight Stack Shield | Metal protective stack shields for safety and a cleaner commercial finish |
| Pulley Ratio | Patented interchangeable 1:1 or 2:1 tri-pulley system |
| Pulley Material | Aluminium alloy |
| Pulley Adjustment | 180 degree swivel triple pulley system with zinc plated adjustment handle and multiple height positions |
| Smith Machine Bearings | Premium linear bearing system on hard chrome guide rails for smooth, quiet travel |
| Smith Bar Rated Capacity | 500kg |
| Smith Bar Weight | 15kg |
| Smith Machine Static Test | 620kg static loading test |
| Smith Plate Compatibility | Accepts Olympic and standard weight plates, stainless steel Olympic sleeves and spring collars included |
| Smith Safety System | Laser cut barbell catch plus 65mm spring buffer for impact absorption |
| Cable Pulley Loading Capacity | 555lb, approximately 252kg |
| J-Cups & Safety Spotters | Fully adjustable with protective ABS and nylon contact pads, 670kg static loading test |
| Dip Handles | Adjustable height, non-slip grips, wide and narrow positions, 340kg static loading test |
| Pull-Up Handles | Multi-angle, non-slip grips, 340kg static loading test, D-ring supports band assisted pull-ups |
| Seated Row Footplate | Integrated flip down metal footplate with non-slip surface, also suitable for calf stretching |
| Resistance Band System | Built-in hooks and pegs allow bands to be combined with Smith machine loading for additional resistance |
| Plate Storage | 6 built-in plate prongs compatible with Olympic and standard plates, individual storage pin listed at 135lb capacity |
| Additional Storage | Swivel accessory hooks, 2 barbell holders, cable attachment rack and rooftop barbell rack |
| Included Cable Accessories | Double-headed straight bar, double-headed curl bar, short straight bar, link chain, triceps rope, ankle strap and close-grip triangle |
| Included Rack Accessories | J-hooks, safety spotter arms, adjustable dip handles/attachment, multi-grip pull-up station, row footplate, plate storage and resistance band pegs |
| Machine Weight | 389 kg |
| Warranty | 10-year frame, 12-month cables and pulleys, 3-month attachments |
| Delivery | Australia-wide freight available |
Pros
- Interchangeable 1:1 and 2:1 pulley ratio suits both heavy compound and light isolation lifts
- Weight stack loading means no need to buy separate plates for the cable towers
- 500kg rated smith bar and heavy gauge 2.5mm steel frame, rated for light commercial use
- Compact 2030mm x 1735mm rack footprint for an all-in-one rig
Cons
- Higher investment than a plate loaded smith machine
- Weight stack tops out at 90kg per side before adding power bands
- Optional attachments such as leg press and monolift are sold separately
Who This Is For
- Home gym owners who want a genuine all-in-one rig without a large commercial footprint.
- PT studios and light commercial facilities such as corporate gyms, hotel gyms or schools, that need fast, pin-loaded weight changes between clients.
- Lifters who train both isolation and compound movements and want one machine that adjusts its pulley ratio to suit each.
This unit is probably not the right fit if you want to load your own Olympic plates rather than use a weight stack, or if your budget favours a plate loaded rig such as the G7S or G5S. If you need a heavier user weight rating for very heavy compound lifting, confirm suitability with our team first.
Need fast weight changes without loading plates? The G9S Pro uses two 90kg pin-loaded weight stacks with an interchangeable 1:1 and 2:1 pulley ratio, so you can move from a light isolation exercise to a heavy compound lift in seconds.
Visit Our Showroom
Showroom10/202 Milperra Road, Milperra NSW 2214Mon to Fri 9am to 5pm. Saturday by appointment only. Sunday closed.Get Directions
Talk To UsPhone: 1300 247 888WhatsApp: +61 412 029 000Email: sales@247gymequipment.com.au
Depot PickupDerrimut, MelbourneArcherfield, Brisbane
Delivery Australia Wide
Australia Wide ShippingDelivered to homes, garages and PT studios across every state.
Installation AvailableAssembly and installation service available. To confirm availability for your postcode.
Dispatch TimeframeTo confirm current lead time at checkout or with our sales team.
You May Also Need
Browse Power Racks and Squat Racks→ Browse Functional Trainers and Smith Machines→ Browse Rack and Machine Attachments→ Browse Gym Flooring→
Frequently Asked Questions
The G9S Pro is rated for light commercial use, suiting personal training studios, corporate and hotel gyms, and schools, in addition to home and garage gyms.
The G9S Pro rack measures 2030mm wide x 1735mm deep x 2130mm tall. Allow additional clearance around the machine for safe access and training.
The G9S Pro includes the Smith machine and power rack frame, two 90kg steel weight stacks with metal shields, the patented interchangeable 1:1 and 2:1 tri-pulley cable system, adjustable J-hooks, safety spotter arms, dip handles and attachment, multi-angle pull-up handles, a flip-down seated row footplate, six plate storage prongs, resistance band pegs, integrated barbell and accessory storage, plus a double-headed straight bar, double-headed curl bar, short straight bar, link chain, triceps rope, ankle strap and close-grip triangle.
No. The G9S Pro uses two built-in 90kg pin-loaded weight stacks rather than plates, though weight plate storage pegs are included for any additional free weight work.
Installation and assembly service is available. Confirm availability and lead time for your postcode with our sales team.
Yes, we deliver the G9S Pro across Australia. Freight cost and timeframe vary by location.
Contact us to confirm current showroom display availability at our Milperra showroom.
The listed test and capacity figures are: 620kg Smith machine static loading test, 555lb cable pulley system loading capacity, 670kg J-cups and safety spotter static loading test, 340kg dip handle static loading test, 340kg chin-up handle static loading test and 135lb per weight storage pin. The Smith bar itself has a stated rated capacity of 500kg.
The G9S Pro includes a 10-year warranty on the frame, 12-month warranty on cables and pulleys, and 3-month warranty on attachments.
The G9S Pro is largely self-contained. Optional attachments such as the leg press, monolift, landmine, rack knee holder and jammer arm are sold separately.
The G9S Pro pairs an interchangeable 1:1 and 2:1 pulley ratio with dual weight stacks within a 2030mm wide x 1735mm deep footprint, which is a strong choice for buyers wanting fast, pin-loaded training without a full commercial floor plan.
The smith machine barbell is rated to a 500kg weight capacity and weighs 15kg itself, running on premium grade linear bearings along the guide rods.
The weight plate storage pegs and smith barbell come fitted with nylon sleeves as standard. These sleeves are removable to accommodate standard plates with the smaller 28mm centre holes.
Yes. The base frame has 2 power band pegs on each side, allowing power bands to be attached to the smith machine bar to increase resistance without loading more weight. A chrome plated D-ring on the pull-up bar also allows power bands to be attached for assisted pull-ups.
Delivery area: We deliver this machine to home gyms, garage gyms and PT studios across Sydney, Melbourne, Brisbane, Adelaide, Canberra, Gold Coast, Newcastle, Wollongong, Hobart and regional Australia.
